Chevrolet Lumina I (1989-2001) harness breakout) Wiring diagram
This page shows the only wiring diagram for the component.harness breakout), which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram harness breakout) (1 of 1)
BATTERY (B+) TRANS POS IN LID LOCK LID LOCK IN
BLK WIRE
BLK/WHT WIRE
BREAKOUT)
DK BLU WIRE
DOOR LOCK RELAY (BEHIND RIGHT SIDE OF DASH)
FUSE 19
FUSE 32
FUSE 39
FUSE BLOCK (ON RIGHT SIDE OF DASH)
GRN WIRE
GROUND
GROUND BREAKOUT)
GRY WIRE
HARNESS BREAKOUT)
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
KEYLESS PROGRAMMING CONNECTOR (RIGHT SIDE OF TRUNK)
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR LOCK SWITCH
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR DOOR LOCK SWITCH
LFT FRT UNLK ALL UNLK
LOCK
LOCK CTRL ILLUM ENTRY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK IGNITION WIRE
PNK WIRE
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT REAR DOOR LOCK SWITCH
RKE PROGRM
TAN WIRE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNLOCK
UNLOCK RELAY LOCK RELAY
W/ KEYLESS ENTRY
W/O KEYLESS ENTRY
WHT WIRE
Go to component -> Power door lock circuit -> HARNESS BREAKOUT)
