Chevrolet Lumina I (1989-2001) front height adjuster motor Wiring diagram
This page shows the only wiring diagram for the component.front height adjuster motor, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front height adjuster motor (1 of 1)
BACK
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER SWITCH
ENTIRE SEAT
FOR- WARD
FORWARD/ BACK ADJUSTER MOTOR
FRONT HEIGHT ADJUSTER MOTOR
FRONT HEIGHT FRONT HEIGHT REAR HEIGHT DOWN
FUSE BLOCK
GRN WIRE
HOT AT ALL TIMES
LT BLU WIRE
NCA WIRE
ORG/ WIRE
POWER SEAT CIRCUIT BREAKER D
REAR HEIGHT
REAR HEIGHT ADJUSTER MOTOR
TAN WIRE
YEL WIRE
Go to component -> 6-way power seat circuit -> FRONT HEIGHT ADJUSTER MOTOR
