Chevrolet Lumina I (1989-2001) engine oil pressure indicator switch engine coolant fan motor 2 Wiring diagram
This page shows the only wiring diagram for the component.engine oil pressure indicator switch engine coolant fan motor 2, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine oil pressure indicator switch engine coolant fan motor 2 (1 of 1)
A/C COMPRESSOR CLUTCH COIL
A/C COMPRESSOR CLUTCH DIODE
BATTERY
BLK WIRE
BRAKE FLUID LEVEL INDICATOR SWITCH
CRUISE CONTROL MODULE
ENGINE COOLANT LEVEL INDICATOR MODULE
ENGINE OIL PRESSURE INDICATOR SWITCH ENGINE COOLANT FAN MOTOR 2
ENGINE WIRING HARNESS JUNCTION BLOCK 1
FUEL PUMP RELAY
HEATED OXYGEN SENSOR 1
HEATED OXYGEN SENSOR 2
HORNS
IGNITION CONTROL MODULE
IGNITION SYST RELAY FAN CONT 2 RELAY
LEFT FRONT PARK/TURN LAMP
LEFT HI BEAM HEADLAMP
LEFT LO BEAM HEADLAMP
MASS AIR FLOW SENSOR ENGINE OIL LEVEL SENSOR
NCA WIRE
POWERTRAIN CONTROL MODULE
RIGHT FRONT PARK/TURN LAMP
RIGHT LO BEAM HEADLAMP
TRANSAXLE RANGE SWITCH
WHT WIRE
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 3) -> ENGINE OIL PRESSURE INDICATOR SWITCH ENGINE COOLANT FAN MOTOR 2
