Chevrolet Lumina I (1989-2001) digital speedometer module Wiring diagrams
This page contains all the electrical diagrams for the component. digital speedometer module, in which he is found in the car Chevrolet Lumina I (1989-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
digital speedometer module wiring diagram (1 of 2)
ACCY BULB LOCK TEST OFF
AIR BAG WARNING IND
ANTI-LOCK BRAKES SYSTEM
ANTI-LOCK BRAKES SYSTEM (ELECTRONIC BRAKE CONTROL MODULE) (EBCM)
ANTI-LOCK WARNING IND
ANTI-THEFT SYSTEM
BLK WIRE
BRAKE FLUID LEVEL INDICATOR SWITCH (ON LEFT SIDE OF BRAKE FLUID RESERVOIR)
BRAKE WARNING IND
BRN WIRE
BRN/WHT WIRE
CHANGE OIL IND CTRL
CHANGE OIL SOON IND
DIGITAL SPEEDOMETER MODULE
DISPLAY SWITCH
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT LEVEL INDICATOR MODULE (ON RIGHT SIDE OF RADIATOR)
ENGINE COOLANT TEMPERATURE GAGE
ENGINE COOLANT TEMPERATURE SENSOR (NEAR COOLANT OUTLET, LEFT REAR OF ENGINE)
ENGINE OIL PRESSURE INDICATOR SWITCH (LEFT SIDE OF ENGINE, ABOVE STARTER)
FASTEN BELTS WARNING IND
FUEL GAGE
FUEL GAGE CONTROL
FUSE 25
FUSE 39
FUSE 4
FUSE BLOCK (RIGHT SIDE OF DASH)
GRY WIRE
GRY/BLK WIRE
HEADLIGHTS SYSTEM
HI-BEAM IND
HOT COOLANT WARNING IND
HOT IN RUN
HOT IN RUN, BULB TEST OR START
IGNITION SWITCH
ILLUMINATION (5 BULBS)
INDICATOR CONTROL
INSTRUMENT CLUSTER
LEFT TURN IND
LOW COOLANT WARNING IND
LOW OIL IND CONTROL
LOW OIL LEVEL IND
LOW TRAC IND
LT BLU WIRE
LT GRN WIRE
MIL IND CONTROL
NCA WIRE
ODO
OIL PRESSURE WARNING IND
ORG/ WIRE
PARK BRAKE INDICATOR SWITCH (PART OF PARK BRAKE ASSEMBLY)
PNK WIRE
POWERTRAIN CONTROL MODULE (FORWARD OF RIGHT SHOCK TOWER)
PPL
RESET+
RIGHT TURN IND
RUN WIRE
SECURITY IND
SEO ACCESSORY SWITCH PANEL
SERVICE ENGINE SOON IND
SUPPLEMENTAL RESTRAINTS SYSTEM STARTING/CHARGING SYSTEM
TACHOMETER
TAN WIRE
TAN/WHT WIRE
TRIP SWITCH
VOLTS WARNING IND
VSS OUT 4000 P/M
WARNING SYSTEM
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Instrument cluster circuit, with seo -> DIGITAL SPEEDOMETER MODULE
digital speedometer module wiring diagram (2 of 2)
4-DOOR 2-DOOR
ACCESSORY SWITCH DISPLAY
AUTOMATIC TRANSMISSION CONTROL POSITION INDICATOR BULB
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DASH ASHTRAY FLOOD LAMP
DASH DIMMER SWITCH
DIGITAL SPEEDOMETER MODULE
ENGINE WIRING HARNESS JUNCTION BLOCK 2
FUSE BLOCK FUSE 39
GRD
GRY WIRE
GRY/BLK WIRE
HEADLAMP SWITCH
HEATER AND A/C CONTROL
HOT AT ALL TIMES PARK LPS FUSE
HOT IN RUN, BULB TEST OR START
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT CLUSTER
LEFT FRONT DOOR LOCK SWITCH
LEFT STEERING WHEEL RADIO CONTROL SWITCH
LIGHTS ON INPUT
NCA WIRE
OFF HEAD PARK
ORG/ WIRE
PNK WIRE
PPL
RADIO
RIGHT FRONT DOOR LOCK SWITCH
RIGHT STEERING WHEEL RADIO CONTROL SWITCH
SEO DIODE
VF DIM INPUT
W/ CONSOLE
W/ SEO
W/O CONSOLE
W/O SEO
WHT WIRE
Go to component -> Instrument illumination circuit -> DIGITAL SPEEDOMETER MODULE
