Chevrolet Lumina I (1989-2001) defog request defog enable defog ind wiring diagram
This page shows the only wiring diagram for the component.defog request defog enable defog ind, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
defog request defog enable defog ind wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
DEFOG REQUEST DEFOG ENABLE DEFOG IND
DEFOGGER IND
DISPLAY DIMMING
EXTERIOR LIGHTS
FUSE 37
FUSE 4
FUSE BLOCK
GROUND
GRY WIRE
HEATER-A/C CONTROL
HOT AT ALL TIMES
HOT IN RUN
IGN
INTERIOR LIGHTS
LT BLU WIRE
NCA WIRE
ORG/ WIRE
PARK LMPS ON
PPL
REAR DEFOGGER SWITCH
REAR WINDOW DEFOGGER GRID
REAR WINDOW DEFOGGER RELAY (BEHIND RIGHT SIDE OF DASH)
Go to component -> Defogger circuit -> DEFOG REQUEST DEFOG ENABLE DEFOG IND
