Chevrolet Lumina I (1989-2001) automatic transmission shift interlock control solenoid Wiring diagram
This page shows the only wiring diagram for the component.automatic transmission shift interlock control solenoid, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic transmission shift interlock control solenoid (1 of 1)
ACCESSORY SWITCH
AUTOMATIC TRANS CONTROL INDICATOR LAMP
AUTOMATIC TRANSMISSION SHIFT INTERLOCK CONTROL SOLENOID
AUXILIARY POWER DROP CONNECTOR
BLK WIRE
BLOWER MOTOR
BLOWER MOTOR RELAY
BLU WIRE
CIGAR LIGHTER
CIRCUIT BREAKER PANEL
DATA LINK CONNECTOR
DAYTIME RUNNING LAMPS CONTROL MODULE
DIGITAL SPEEDOMETER MODULE (INSTRUMENT CLUSTER)
ELECTRONIC BRAKE CONTROL MODULE
FUSE 25
FUSE BLOCK
HAZARD LAMP/ TURN SIGNAL LAMP FLASHER
HEADLAMP SWITCH
HEATER-A/C CONTROL
I/P ASHTRAY FLOOD LAMP CIGAR LIGHTER
I/P COMPARTMENT LAMP SWITCH
INFLATABLE RESTRAINT SENSING AND DIAGNOSTIC MODULE
INSIDE REARVIEW MIRROR
INSTRUMENT CLUSTER
LEFT ELECTRIC ACTUATOR
LEFT STEERING WHEEL RADIO CONTROL SWITCH
NCA WIRE
RADIO
RELAY RELAY
RIGHT ELECTRIC ACTUATOR
RIGHT STEERING WHEEL RADIO CONTROL SWITCH
SEAT BELT/ IGNITION KEY/ LAMPS ALARM
SEO ONLY
SIR COIL
STEERING COLUMN BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID
SUNROOF CONTROL MODULE
SUNROOF SWITCH
THEFT DETERRENT MODULE
W/ CONSOLE
W/O CONSOLE
WHT WIRE
Go to component -> Ground distribution circuit (2 of 3) -> AUTOMATIC TRANSMISSION SHIFT INTERLOCK CONTROL SOLENOID
