Chevrolet Lumina I (1989-2001) automatic transmission control position indicator bulb Wiring diagram
This page shows the only wiring diagram for the component.automatic transmission control position indicator bulb, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic transmission control position indicator bulb (1 of 1)
4-DOOR 2-DOOR
ACCESSORY SWITCH DISPLAY
AUTOMATIC TRANSMISSION CONTROL POSITION INDICATOR BULB
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DASH ASHTRAY FLOOD LAMP
DASH DIMMER SWITCH
DIGITAL SPEEDOMETER MODULE
ENGINE WIRING HARNESS JUNCTION BLOCK 2
FUSE BLOCK FUSE 39
GRD
GRY WIRE
GRY/BLK WIRE
HEADLAMP SWITCH
HEATER AND A/C CONTROL
HOT AT ALL TIMES PARK LPS FUSE
HOT IN RUN, BULB TEST OR START
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT CLUSTER
LEFT FRONT DOOR LOCK SWITCH
LEFT STEERING WHEEL RADIO CONTROL SWITCH
LIGHTS ON INPUT
NCA WIRE
OFF HEAD PARK
ORG/ WIRE
PNK WIRE
PPL
RADIO
RIGHT FRONT DOOR LOCK SWITCH
RIGHT STEERING WHEEL RADIO CONTROL SWITCH
SEO DIODE
VF DIM INPUT
W/ CONSOLE
W/ SEO
W/O CONSOLE
W/O SEO
WHT WIRE
Go to component -> Instrument illumination circuit -> AUTOMATIC TRANSMISSION CONTROL POSITION INDICATOR BULB
