Power top/sunroof circuit, with dic for Chevrolet Impala VIII (1999-2006)
Power top/sunroof circuit, with dic
BLK WIRE
BRN WIRE
CLOSE
CLOSE SIG
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC)
GROUND
HOT IN ACC, ON, RAP
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL)
LOW REF
NCA WIRE
OPEN SIG
ORG/ WIRE
RED WIRE
RETAINED ACCESSORY POWER CIRCUIT BREAKER
SOFT STOP
STOP INPUT
SUN ROOF MODULE (IN ROOF, NEAR WINDSHIELD)
SUN ROOF MOTOR (AT CENTER LEFT OF WINDSHIELD HEADER)
SUN ROOF OPENING POSITION SWITCH (ABOVE SUN ROOF MOTOR)
VENT
VENT INPUT
YEL WIRE
