Instrument illumination circuit for Chevrolet Impala VIII (1999-2006)

Instrument illumination circuit (1 of 2)

Impala Chevrolet VIII (1999-2006): Instrument illumination circuit (1 of 2)

Get access

BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH, ABOVE PARKING BRAKE LEVER) BRN WIRE FULL BRIGHT GRY WIRE GRY/BLK WIRE HEAD PARK LAMP SWITCH HEADLAMP SWITCH HOT AT ALL TIMES I/P DIMMING SWITCH INT DIM CTRL RELAY CTRL GROUND GROUND GROUND LEFT CRUISE CONTROL (SET/ COAST) LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL) LEFT RADIO CONTROL (SEEK/ PRESET) LOW DIM LT BLU WIRE NCA WIRE OFF PARK PARK LAMP RELAY PARK LAMP SWITCH INPUT REAR PARK LMP FUSE RED WIRE RIGHT CRUISE CONTROL (RESUME/ ACCEL) RIGHT I/P 1 FUSE RIGHT I/P JUNCTION BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) RIGHT RADIO CONTROL (VOLUME/ MODE) STEERING COLUMN FUSE STEERING WHEEL) TO HVAC CONTROL MODULE (DIAGRAM 2 OF 2) TO LEFT I/P JUNCTION BLOCK (DIAGRAM 2 OF 2) UNDERHOOD JUNCTION BLOCK (TOP) (ON FRONT OF RIGHT STRUT TOWER) WHT WIRE

Instrument illumination circuit (2 of 2)

Impala Chevrolet VIII (1999-2006): Instrument illumination circuit (2 of 2)

Get access

ACCESS PANEL) ASHTRAY LAMP (W/O FRONT CONSOLE) BLK WIRE DIM INPUT DRIVER HEATED SEAT SWITCH (MONTE CARLO) FOG LAMP SWITCH (IF EQUIPPED) FROM LEFT I/P JUNCTION BLOCK (DIAGRAM 1 OF 2) FROM LEFT I/P JUNCTION BLOCK (DIAGRAM 2 OF 2) FRONT PASSENGER DOOR LOCK SWITCH FRONT PASSENGER HEATED SEAT SWITCH (MONTE CARLO) FRONT PASSENGER WINDOW SWITCH GRY WIRE HAZARD SWITCH HVAC CONTROL MODULE INSTRUMENT PANEL CLUSTER (IPC) (9 BULBS) LEFT I/P JUNCTION BLOCK LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, BEHIND OUTSIDE REARVIEW MIRROR SWITCH DRIVER DOOR LOCK SWITCH RADIO RIGHT I/P JUNCTION BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) SURVEILLANCE MODE SWITCH TO LEFT I/P JUNCTION BLOCK (DIAGRAM 2 OF 2) TRACTION CONTROL SWITCH (IMPALA) TRACTION CONTROL SWITCH (MONTE CARLO) W/ POLICE, LIMITED CONTENT W/O POLICE, LIMITED CONTENT WHT WIRE
