Headlights circuit, with police or emergency vehicle option for Chevrolet Impala VIII (1999-2006)

AC HEADLAMP RELAY AMBIENT LIGHT SENSOR (TOP RIGHT OF DASH, NEAR DEFOGGER OUTLET) BLK WIRE BLK/WHT WIRE BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL) BLUNT CUT WIRE PNK BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH, ABOVE PARKING BRAKE LEVER) BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN/WHT WIRE DRL RELAY DRL RELAY SERIAL DATA FOG LP RELAY HIGH BEAM IN HEADLAMP RLY DRL/EXT LTS FUSE EMERGENCY VEHICLE HEADLAMPS FLASHER (FORWARD OF RADIATOR SUPPORT) EXT LTS FUSE FOG LAMP INDICATOR FOG LAMP SWITCH FOG LIGHT RELAY FOG LP SW PARK BRAKE IN FOG RLY FUSE GROUND DISTRIBUTION SYSTEM GRY WIRE HEAD HEADLAMP DIMMER SWITCH HEADLAMP SW AL SENS SIG AL SENS REF 1138 1137 HEADLAMP SWITCH HIGH BEAM HIGH BEAM IND MESSAGE CENTER HIGH BEAM OUT HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) IPC CLASS 2 SERIAL DATA LEFT FRONT FOG LAMP LEFT HEADLAMP LEFT I/P JUNCTION LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL) LOGIC LOW BEAM LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE OFF ORG/ WIRE PARK PARK BRAKE SWITCH (AT BASE OF PARKING BRAKE ASSEMBLY) PNK PNK WIRE PNK WIRE PPL RIGHT FRONT FOG LAMP RIGHT HEADLAMP LOW BEAM TURN SIGNAL/ MULTIFUNCTION SWITCH (IN STEERING COLUMN) UNDERHOOD JUNCTION BLOCK (TOP) YEL WIRE YEL/BLK WIRE
