Chevrolet Impala VIII (1999-2006) w/ rear compt lid emergency lamp package Wiring diagram
This page shows the only wiring diagram for the component.w/ rear compt lid emergency lamp package, which is found in the car Chevrolet Impala VIII (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ rear compt lid emergency lamp package (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH, ABOVE PARKING BRAKE LEVER)
BRN WIRE
DIC/ RKE FUSE
DRIVER INFORMATION CENTER
EMERGENCY VEHICLE REAR COMPARTMENT LID LAMPS RELAY
HOT AT ALL TIMES
LEFT EMERGENCY VEHICLE REAR COMPARTMENT LID LAMP
LEFT SPOT LAMP
LEFT SPOT LMP FUSE
NCA WIRE
ORG/ WIRE
REAR COMPARTMENT LID AJAR SWITCH
RED/BLK WIRE
RIGHT EMERGENCY VEHICLE REAR COMPARTMENT LID LAMP
RIGHT I/P JUNCTION BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
RIGHT SPOT LAMP
RIGHT SPOT LMP FUSE
TAN WIRE
UNDERHOOD JUNCTION BLOCK (TOP) (ON FRONT OF RIGHT STRUT TOWER)
W/ DRIVER INFORMATION DISPLAY CENTER
W/ REAR COMPT LID EMERGENCY LAMP PACKAGE
YEL WIRE
Go to component -> Accessory lamps circuit -> W/ REAR COMPT LID EMERGENCY LAMP PACKAGE
