Chevrolet Impala VIII (1999-2006) turn signal/ multifunction switch wiring diagram

AC HEADLAMP RELAY AMBIENT LIGHT SENSOR (TOP RIGHT OF DASH, NEAR DEFOGGER OUTLET) BLK WIRE BLK/WHT WIRE BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL) BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH, ABOVE PARKING BRAKE LEVER) BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN/WHT WIRE DRL RELAY DRL RELAY SERIAL DATA FOG LP RELAY HIGH BEAM IN HEADLAMP RLY DRL/EXT LTS FUSE EXT LTS FUSE FOG LAMP INDICATOR FOG LAMP SWITCH FOG LIGHT RELAY FOG LP SW PARK BRAKE IN GROUND DISTRIBUTION SYSTEM GRY WIRE HEAD HEADLAMP DIMMER SWITCH HEADLAMP SW AL SENS SIG AL SENS REF 1138 1137 HEADLAMP SWITCH HIGH BEAM HIGH BEAM IND HIGH BEAM OUT HOT AT ALL TIMES IPC CLASS 2 SERIAL DATA LEFT FRONT FOG LAMP LEFT HEADLAMP LEFT I/P JUNCTION LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL) LOGIC INSTRUMENT PANEL CLUSTER (IPC) LOW BEAM LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MESSAGE CENTER OFF ORG/ WIRE PARK PARK BRAKE SWITCH (AT BASE OF PARKING BRAKE ASSEMBLY) PNK PNK WIRE PNK WIRE PPL RIGHT FRONT FOG LAMP RIGHT HEADLAMP LOW BEAM TURN SIGNAL/ MULTIFUNCTION SWITCH UNDERHOOD JUNCTION BLOCK (TOP) UNDERHOOD JUNCTION BLOCK (TOP) (ON FRONT OF RIGHT STRUT TOWER) UNDERHOOD JUNCTION BLOCK (TOP) FOG RLY FUSE YEL WIRE YEL/BLK WIRE
