Chevrolet Impala VIII (1999-2006) trk/roof brp fuse Wiring diagram
This page shows the only wiring diagram for the component.trk/roof brp fuse, which is found in the car Chevrolet Impala VIII (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trk/roof brp fuse (1 of 1)
BATT RUNDOWN PROTECTION RELAY
BEHIND ACCESS PANEL)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH, ABOVE PARKING BRAKE LEVER)
COURTESY LMP RLY CTRL LOW CTRL GROUND
CRTSY LMP V
DIC/ RKE FUSE
DK BLU WIRE
DK BLU/WHT WIRE
DK DK
DOME OFF SURVEILLANCE MODE SWITCH (W/ POLICE PACKAGE, LIMITED CONTENT)
HEADLAMP SWITCH PPL
HOT AT ALL TIMES
I/P BRP FUSE
LEFT I/P COURTESY LAMP
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL)
NCA WIRE
ORG/ WIRE
PPL MODE SW SIG DOME LMP SW
REAR COMPARTMENT LID AJAR SWITCH
RED WIRE
RED/BLK WIRE
RIGHT I/P COURTESY LAMP
RIGHT I/P JUNCTION BLOCK (RIGHT SIDE OF DASH,
TO SPLICE
TRK/ROOF BRP FUSE
WHT WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> TRK/ROOF BRP FUSE
