Chevrolet Impala VIII (1999-2006) release ctrl trunk ajar sw Wiring diagram
This page shows the only wiring diagram for the component.release ctrl trunk ajar sw, which is found in the car Chevrolet Impala VIII (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram release ctrl trunk ajar sw (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM)
CLASS 2 SER DATA SERIAL DATA
COMPUTER DATA LINES SYSTEM
DIC/RKE FUSE
GRY WIRE
HOT AT ALL TIMES
INPUT
INSTRUMENT PANEL CLUSTER (IPC)
INTERIOR, EXTERIOR LIGHTS SYSTEMS
IPC CLASS 2 SERIAL DATA
LOGIC
LT BLU WIRE
LT GRN WIRE
MESSAGE CENTER TRUNK OPEN
NCA WIRE
ORG/ WIRE
REAR COMPARTMENT LID AJAR SWITCH
REAR COMPARTMENT LID RELEASE ACTUATOR
REAR COMPARTMENT LID RELEASE SWITCH
RED/BLK WIRE
RED/WHT WIRE
RELEASE CTRL TRUNK AJAR SW
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (ON UPPER CENTER OF DASH)
RIGHT I/P JUNCTION BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
SERIAL DATA
WHT WIRE
Go to component -> Trunk release circuit -> RELEASE CTRL TRUNK AJAR SW
