Chevrolet Impala VIII (1999-2006) rear defogger momentary switch Wiring diagram
This page shows the only wiring diagram for the component.rear defogger momentary switch, which is found in the car Chevrolet Impala VIII (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defogger momentary switch (1 of 1)
ABOVE PARKING BRAKE LEVER)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BRN WIRE
DRIVER OUTSIDE REARVIEW MIRROR
GRN WIRE
HOT AT ALL TIMES
HOT IN ON A/C CRUISE FUSE
HTD MIR FUSE
HVAC CONTROL MODULE
LEFT I/P JUNCTION BLOCK
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL)
LOAD MANAGEMENT CONTROL
LOGIC IGN REAR DEFOG RLY CTRL
NCA WIRE
ORG/ WIRE
PASSENGER OUTSIDE REARVIEW MIRROR
PNK WIRE
RADIO ANTENNA MODULE (ON UPPER PORTION OF LEFT "C" PILLAR)
REAR DEFOG CIRCUIT BREAKER
REAR DEFOG RELAY
REAR DEFOGGER MOMENTARY SWITCH
REAR WINDOW REAR WINDOW DEFOGGER GRID
RED WIRE
RIGHT I/P JUNCTION BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
RT IP 3 FUSE
UNDERHOOD JUNCTION BLOCK (BOTTOM) (ON FRONT OF RIGHT STRUT TOWER)
WHT WIRE
Go to component -> Defoggers circuit -> REAR DEFOGGER MOMENTARY SWITCH
