Chevrolet Impala VIII (1999-2006) power seats circuit breaker Wiring diagram
This page shows the only wiring diagram for the component.power seats circuit breaker, which is found in the car Chevrolet Impala VIII (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power seats circuit breaker (1 of 1)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT REAR VERTICAL MOTOR
FORWARD/
FRONT DOWN
FRONT PASSENGER SEAT ADJUSTER MOTOR ASSEMBLY
FRONT PASSENGER SEAT ADJUSTER SWITCH
FRONT PASSENGER SEAT FRONT VERTICAL MOTOR
FRONT PASSENGER SEAT HORIZONTAL MOTOR
FRONT PASSENGER SEAT REAR VERTICAL MOTOR
FRONT UP BACK
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
POWER SEATS CIRCUIT BREAKER
REAR DOWN
REAR UP
REAR UP FRONT DOWN
RIGHT I/P JUNCTION BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
TAN WIRE
YEL WIRE
