Chevrolet Impala VIII (1999-2006) headlamp switch right headlamp connector breakout) Wiring diagram

3 9 (W/O GPS) (W/ GPS) AUXILIARY DOME LAMP INSIDE REARVIEW MIRROR B/U LP FUSE BACK-UP LP RELAY BATT RUNDOWN PROTECTION RELAY BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRN WIRE DIC/RKE FUSE DK BLU WIRE DOME LAMP (W/O READING LAMP) DRIVER INFORMATION CENTER (DIC) DRIVER SEAT ADJUSTER SWITCH FRONT PASSENGER SEAT ADJUSTER SWITCH EMERGENCY VEHICLE REAR COMPARTMENT LID LAMPS RELAY FROM UNDERHOOD JUNCTION BLOCK (TOP) (DIAGRAM 1 OF 5) FRONT PARK LP FUSE FRONT PASSENGER HEATED SEAT RELAY (W/ HEATED SEATS) GRN WIRE HEADLAMP SWITCH RIGHT HEADLAMP CONNECTOR BREAKOUT) HVAC CONTROL MODULE I/P BRP FUSE IMPALA LEFT BACKUP LAMP RIGHT BACKUP LAMP LEFT BACKUP LAMP LEFT COURTESY/ READING LAMP RIGHT COURTESY/ READING LAMP LEFT HEADLAMP LEFT I/P COURTESY LAMP LICENSE LAMP LT GRN WIRE LT INSIDE REARVIEW MIRROR (W/ READING LAMPS) MONTE CARLO MONTE CARLO IMPALA NCA WIRE ORG/ WIRE PARK LP RELAY PWR DROP FUSE PWR SEATS CIRCUIT BREAKER REAR COMPART- MENT COURTESY LAMP REAR COMPARTMENT OCCUPANT SENSOR REAR PRK LP FUSE RED WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (W/O SEO) RH HTD ST FUSE RIGHT BACKUP LAMP RIGHT HEADLAMP RIGHT I/P COURTESY LAMP RIGHT LICENSE LAMP LEFT LICENSE LAMP RIGHT TAIL LAMP LEFT TAIL LAMP RIGHT VANITY MIRROR LAMP LEFT VANITY MIRROR LAMP TO AUXILIARY POWER DROP CONNECTOR (DIAGRAM 5 OF 5) TRK/ ROOF BRP FUSE VEHICLE COMMUNICATION INTERFACE MODULE W/ GPS W/ GPS W/O GPS W/ SEO WHT WIRE YEL WIRE
