Chevrolet Impala VIII (1999-2006) (forward lamp wiring harness, near left headlamp, 18.5 Wiring diagram
This page shows the only wiring diagram for the component.(forward lamp wiring harness, near left headlamp, 18.5, which is found in the car Chevrolet Impala VIII (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (forward lamp wiring harness, near left headlamp, 18.5 (1 of 1)
BLK WIRE
BREAKOUT)
DK BLU WIRE
DK GRN WIRE
ECT GND
ECT SIG
ENGINE CONTROLS SYSTEM
FAN CONT 1 FUSE
FAN CONT 1 RELAY
FAN CONT 2 RELAY
FAN CONT 2, 3 FUSE
FAN CONT 3 RELAY
GRY WIRE
HIGH SPD
HOT AT ALL TIMES
LEFT COOLING FAN (FRONT OF ENGINE COMPT)
LOW SPD
LT BLU WIRE
ORG/ WIRE
ORG/BLK WIRE
POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER BOX)
RIGHT COOLING FAN (FRONT OF ENGINE COMPT)
UNDERHOOD JUNCTION BLOCK (BOTTOM) (ON FRONT OF RIGHT STRUT TOWER)
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> (FORWARD LAMP WIRING HARNESS, NEAR LEFT HEADLAMP, 18.5
