Chevrolet Impala VIII (1999-2006) dash, behind access panel) power distribution system Wiring diagram
This page shows the only wiring diagram for the component.dash, behind access panel) power distribution system, which is found in the car Chevrolet Impala VIII (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dash, behind access panel) power distribution system (1 of 1)
ABOVE PARKING BRAKE LEVER)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
CLSTR/BCM FUSE
DASH, BEHIND ACCESS PANEL) POWER DISTRIBUTION SYSTEM
DATA CLASS 2
DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
DIGITAL RADIO RECEIVER (IF EQUIPPED) (RIGHT REAR OF WHEELWELL)
DK BLU WIRE
DK DK
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) (IF EQUIPPED)
EXCEPT POLICE VEHICLE, TAXI
GRY WIRE
HOT AT ALL TIMES
HVAC CONTROL MODULE (MIDDLE CENTER OF DASH)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (BELOW PASSENGER'S SEAT)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF
LT BLU WIRE
LT GRN WIRE
ONSTAR MODULE (W/ VEHICLE COMMUNICATION SYSTEM)
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER BOX)
PPL
RADIO
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit -> DASH, BEHIND ACCESS PANEL) POWER DISTRIBUTION SYSTEM
