Chevrolet Impala VIII (1999-2006) blower motor control processor Wiring diagram

AUDIO AMPLIFIER (W/ PERFORMANCE ENHANCED SPEAKER) BATTERY BLK WIRE BLK/WHT WIRE BLOWER MOTOR CONTROL PROCESSOR BLUNT CUT WIRE AT RIGHT FRONT FLOOR BREAKOUT) CIRCUIT BREAKER 1 CIRCUIT BREAKER 2 CIRCUIT BREAKER 3 COOLING FANS FUSE CRANK RLY RELAY DK GRN WIRE DRIVER OUTSIDE REARVIEW MIRROR DIGITAL RADIO RECEIVER (W/ DIGITAL RADIO) ELECTRONIC BRAKE CONTROL MODULE (EBCM) FROM CRANK RELAY (DIAGRAM 2 OF 5) FROM RIGHT I/P 3 FUSE (DIAGRAM 1 OF 5) FUSE BLOCK (SEO) (BEHIND DASH, RIGHT OF STEERING COLUMN) FUSIBLE LINK FUSIBLE LINK (10 GA-RUST) FUSIBLE LINK FUSIBLE LINK GENERATOR HTD MIR FUSE HVAC BLOWER FUSE IGN RLY RELAY IGN SW FUSE LEFT I/P FUSE LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, BEHIND ACCESS PANEL) NCA WIRE ORG/ WIRE PASSENGER OUTSIDE REARVIEW MIRROR PNK WIRE RADIO RADIO ANTENNA MODULE RADIO FUSE REAR BRKR DEFOG CIRCUIT BREAKER REAR DEFOG RELAY REAR JUNCTION BLOCK (BEHIND RIGHT REAR WHEELWELL) RED WIRE RIGHT I/P 1 FUSE RIGHT I/P 2 FUSE RIGHT I/P 3 FUSE SEO RELAY SEO RELAY STARTER TO FAN CONT 1 FUSE (DIAGRAM 3 OF 5) TO IGNITION SWITCH (DIAGRAM 2 OF 5) TO LEFT I/P JUNCTION BLOCK (DIAGRAM 3 OF 5) TO REAR DEFOG RELAY (DIAGRAM 1 OF 5) TO RIGHT I/P JUNCTION BLOCK (DIAGRAM 4 OF 5) TO RIGHT I/P JUNCTION BLOCK (DIAGRAM 5 OF 5) TO UNDERHOOD JUNCTION BLOCK (BOTTOM) (DIAGRAM 3 OF 5) TO UNDERHOOD JUNCTION BLOCK (TOP) (DIAGRAM 5 OF 5) U/HOOD 1 FUSE U/HOOD 2 FUSE UNDERHOOD JUNCTION BLOCK (TOP) UNDERHOOD JUNCTION BLOCK (TOP) (ON FRONT OF RIGHT STRUT TOWER) W/ SEO
