Chevrolet Impala VIII (1999-2006) 59 5 6 13 80 class 2 serial high speed low speed ect ground low reference Wiring diagram
This page shows the only wiring diagram for the component.59 5 6 13 80 class 2 serial high speed low speed ect ground low reference, which is found in the car Chevrolet Impala VIII (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 59 5 6 13 80 class 2 serial high speed low speed ect ground low reference (1 of 1)
39 26 27 34 COMP CONTROL ECT SIGNAL A/C PRESS SIGNAL
59 5 6 13 80 CLASS 2 SERIAL HIGH SPEED LOW SPEED ECT GROUND LOW REFERENCE
A/C CMPR RELAY
A/C COMPRESSOR CLUTCH
A/C REFRIGERANT PRESSURE SENSOR (ON LEFT SIDE OF ENGINE COMPT, ON LIQUID LINE)
A/C REQUEST IND
A/C REQUEST SIG
A/C REQUEST SWITCH
A/C RLY (CMPR) FUSE
A/C RLY (COIL) FUSE
BATTERY POSITIVE
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR
BLOWER MOTOR (ON RIGHT BOTTOM OF HEATER-A/C ASSEMBLY)
BLOWER MOTOR CONTROL PROCESSOR (LOWER RIGHT SIDE OF DASH)
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH, ABOVE PARKING BRAKE LEVER)
BREAKOUT)
BREAKOUT) (3.8L (VIN K): LEFT REAR OF ENGINE, 6.5 CM FROM EGR VALVE BREAKOUT)
BRN WIRE
COMPUTER DATA LINES SYSTEM
D TEMP CONTROL SWITCH
DEFOG SWITCH
DEFOGGER SYSTEM COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DR CTRL A DR CTRL B DR CTRL A DR CTRL B DOOR CTRL A DOOR CTRL B
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE
FAN CONT 1 FUSE
FAN CONT 1 RELAY
FAN CONT 2 RELAY
FAN CONT 2, 3 FUSE
FAN CONT 3 RELAY
GROUND
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ON
HVAC BLOWER FUSE
HVAC CLASS 2 SERIAL DATA
HVAC CLASS 2 SERIAL DATA BATTERY
ILLUM
LEFT AIR TEMPERATURE ACTUATOR (ON LEFT SIDE OF HEATER- A/C ASSEMBLY)
LEFT COOLING FAN (FRONT OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MODE ACTUATOR (LOWER RIGHT SIDE OF DASH)
MODE SWITCH
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
OUT SIDE AIR IND
OUT SIDE AIR SWITCH
P TEMP CONTROL SWITCH
PNK IGN 3 VOLT GROUND WIRE
PNK WIRE
PNK/WHT WIRE
POWER DISTRIBUTION SYSTEM
PPL
REAR DEFOG RLY CTRL
RECIRCULATION ACTUATOR
RECIRCULATION IND
RECIRCULATION SWITCH
RED WIRE
RED/BLK WIRE
RIGHT AIR TEMPERATURE ACTUATOR (ON RIGHT SIDE OF HEATER- A/C ASSEMBLY)
RIGHT COOLING FAN (FRONT OF ENGINE COMPT)
S121 (3.4L (VIN E)) (FUEL INJECTOR JUMPER
SPEED CTRL
SPEED CTRL DOOR CTRL POSITION SIG
STARTER
SUPPLY VOLTAGE
TAN WIRE
UNDERHOOD JUNCTION BLOCK (TOP) (ON FRONT OF RIGHT STRUT TOWER)
VOLTAGE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit -> 59 5 6 13 80 CLASS 2 SERIAL HIGH SPEED LOW SPEED ECT GROUND LOW REFERENCE
