Chevrolet Impala VIII (1999-2006) 1 2 ground pump mtr ctrl Wiring diagram

1 2 3 4 5 6 7 GND IGN VOL 1 BUS + BUS - PNK WIRE 1 2 GROUND PUMP MTR CTRL 20 40 DELIVERED TORQUE REQUESTED TORQUE 3.8L ABS ABS FUSE ABS MTR FUSE ABS SOL FUSE ABS/TCS ABS/TCS YAW RATE SENS REQ TORQUE 5 VOLT REF BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN) BRAKE FLUID PRESSURE SENSOR (W/ ACTIVE HANDLING) BRAKE PRESSURE MODULATOR VALVE (MOUNTED TO LEFT STRUT TOWER) BRN WIRE BRN/WHT WIRE DK BLU WIRE DK GRN WIRE DRIVER INFORMATION CENTER (DIC) ELECTRONIC POWER STEERING SYSTEM ENG SPEED SIG GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN OR START IND B+ INSTRUMENT PANEL CLUSTER (IPC) IPC ABS/TCS LEFT FRONT WHEEL SPEED SENSOR (VSS) (ON LEFT FRONT BEARING, HUB ASSEMBLY) LEFT REAR WHEEL SPEED SENSOR (VSS) (ON LEFT REAR BEARING, HUB ASSEMBLY) LOGIC LOGIC ABS/TCS LT BLU WIRE LT GRN WIRE MESSAGE CENTER NCA WIRE ORG/ WIRE ORG/BLK WIRE PCM CLASS 2 PNK PNK WIRE PNK WIRE PPL PUMP MOTOR RED WIRE RIGHT FRONT WHEEL SPEED SENSOR (VSS) (ON RIGHT FRONT BEARING, HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (VSS) (ON RIGHT REAR BEARING, HUB ASSEMBLY) STABILITY OFF IND (W/ ACTIVE HANDLING) STEERING ANGLE SENSOR (W/ ACTIVE HANDLING) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TRACTION CONTROL SWITCH TRACTION STABILITY CONTROL CONTROL ACTIVE ACTIVE TRIP COMPUTER UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER) VARIABLE EFFORT VARIABLE EFFORT W/O ACTIVE HANDLING WHT WIRE YEL WIRE
