Car Wiring Diagrams for Radio circuits for Chevrolet Impala VII (1994-1996)

ANTENNA ANTENNA INPUT BATTERY POWER BLK/WHT WIRE BRN WIRE COAXIAL CABLE DIM SIGNAL DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROLS SYSTEM GROUND GRY WIRE HOT AT ALL TIMES HOT IN ACCY OR RUN I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH) IGNITION POWER LEFT FRONT SPEAKER LEFT REAR SPEAKER LT BLU WIRE LT FRT SPKR LT GRN WIRE LT REAR SPKR ON OUTPUT ORG/ WIRE PANEL LIGHT POWER ANTENNA SYSTEM RADIO RADIO FUSE RIGHT FRONT SPEAKER RIGHT REAR SPEAKER RT FRT SPKR RT REAR SPKR SPEED COMPENSATED VOLUME TAN WIRE YEL WIRE
