Back-up lamps circuit for Chevrolet Impala VII (1994-1996)
Back-up lamps circuit
AUTO DAY/ NIGHT MIRROR
BACKUP LAMP, TRANSMISSION POSITION SENSOR SWITCH (NEAR BASE OF STEERING COLUMN)
BLK WIRE
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (BEHIND LEFT I/P)
LEFT BACKUP LIGHT
LT GRN WIRE
PNK WIRE
RIGHT BACKUP LIGHT
RIGHT BACKUP LIGHT LEFT BACKUP LIGHT
SEDAN
T/SIG FUSE
TURN SIGNAL LAMP FLASHER PNK WIRE
WAGON
