Chevrolet Impala VII (1994-1996) vss input 4000 pulses per mile Wiring diagram

1.3 K V REF LO 1995 VFTC STEERING WHEEL SPEED SENSOR 29.6 29.6 790 K V REF HI 29.6 K 7 TO 15 OHMS BLK WIRE BRN WIRE DATA LINK CONNECTOR DK GRN WIRE DK GRN/WHT WIRE ENABLE GROUND HOT IN RUN I/P FUSE BLOCK IGNITION INPUT LT BRN WIRE LT GRN WIRE POWER STEERING CONTROL MODULE POWER STEERING FLUID RESERVOIR P/S PUMP FITTING EVO ACTUATOR POWERTRAIN CONTROL MODULE PULSE WIDTH MODULATED OUTPUT CONTROL RED WIRE SOLID STATE STEERING WHEEL ROTATION SENSE V REF LO VEHICLE SPEED OUTPUT 4000 PULSE/MILE VEHICLE SPEED SENSOR VES FUSE 8 10 AMP VSS INPUT 4000 PULSES PER MILE WHT WIRE
