Chevrolet Impala VII (1994-1996) steering column brake transmission shift interlock solenoid Wiring diagram
This page shows the only wiring diagram for the component.steering column brake transmission shift interlock solenoid, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column brake transmission shift interlock solenoid (1 of 1)
1995 VFTC
BACKUP LAMP, TRANSMISSION POSITION SENSOR SWITCH
BLK WIRE
BRAKE TRANSMISSION SHIFT INTERLOCK (BTSI) SWITCH (BRAKE PEDAL SUPPORT)
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
LT GRN WIRE
LT GRN/WHT WIRE
PNK WIRE
REMOTE CONTROL DOOR LOCK RECEIVER
STEERING COLUMN BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID
T/SIG FUSE 12
Go to component -> Shift interlock circuit -> STEERING COLUMN BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID
