Chevrolet Impala VII (1994-1996) rectifier bridge Wiring diagram
This page shows the only wiring diagram for the component.rectifier bridge, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rectifier bridge (1 of 1)
1995 VFTC
BATTERY
BLK WIRE
BRN WIRE
DC SENSE TURN ON INPUT AC SENSE
FIELD (ROTOR)
GENERATOR (RIGHT SIDE OF ENGINE, FORWARD OF RIGHT VALVE COVER) TURN ON INPUT
HOT IN RUN OR START
HOT IN RUN SEC FAN FUSE 8
I/P FUSE BLOCK
I/P INDC FUSE #11
INSTRUMENT CLUSTER
PNK WIRE
POWER DISTRIBUTION
RECTIFIER BRIDGE
REGULATOR (SOLID STATE)
STARTER SOLENOID
STATOR
UNDERHOOD ELECTRICAL CENTER
VOLTS IND. CHECK GAGE IND. *BUICK **CHEVY
Go to component -> Charging circuit -> RECTIFIER BRIDGE
