Chevrolet Impala VII (1994-1996) left rear side window switch dn Wiring diagram
This page shows the only wiring diagram for the component.left rear side window switch dn, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear side window switch dn (1 of 1)
1995 VFTC
BLK WIRE
BRN WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DN UP
EXPRESS DOWN MODULE
HOT IN RUN
I/P FUSE BLOCK
LEFT FRONT SIDE WINDOW REGULATOR MOTOR
LEFT REAR SIDE WINDOW REGULATOR MOTOR
LEFT REAR SIDE WINDOW SWITCH DN
LT BLU WIRE
LT GRN WIRE
MASTER SIDE WINDOW SWITCH
PPL
PWR WDO CIRCUIT BREAKER 2
RIGHT FRONT SIDE WINDOW REGULATOR MOTOR
RIGHT FRONT SIDE WINDOW SWITCH DN
RIGHT REAR SIDE WINDOW REGULATOR MOTOR
RIGHT REAR SIDE WINDOW SWITCH DN UP
SIDE WINDOW LOCK- OUT SWITCH
TAN WIRE
Go to component -> Power window circuit -> LEFT REAR SIDE WINDOW SWITCH DN
