Chevrolet Impala VII (1994-1996) left backup light Wiring diagram
This page shows the only wiring diagram for the component.left backup light, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left backup light (1 of 1)
AUTO DAY/ NIGHT MIRROR
BACKUP LAMP, TRANSMISSION POSITION SENSOR SWITCH (NEAR BASE OF STEERING COLUMN)
BLK WIRE
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (BEHIND LEFT I/P)
LEFT BACKUP LIGHT
LT GRN WIRE
PNK WIRE
RIGHT BACKUP LIGHT
RIGHT BACKUP LIGHT LEFT BACKUP LIGHT
SEDAN
T/SIG FUSE
TURN SIGNAL LAMP FLASHER PNK WIRE
WAGON
