Chevrolet Impala VII (1994-1996) i/p compart- ment lamp Wiring diagram
This page shows the only wiring diagram for the component.i/p compart- ment lamp, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram i/p compart- ment lamp (1 of 1)
1995 VFTC
AUXILIARY DOME LAMP
BASE
BLK WIRE
BLU WIRE
CLUS CHI FUSE #33
CONVENIENCE CENTER (BEHIND LEFT SIDE OF I/P)
COURTESY SWITCH
CTSY PWR LOCK FUSE 35
DK BLU WIRE
DK BLU/WHT WIRE
DK DK
DK GRN WIRE
DOME COURTESY LAMP RELAY
DOME LAMP
DOOR COURTESY LAMPS
DOOR JAMB SWITCHES
ENDGATE LOWER LOCK AJAR SWITCH
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDERHOOD ELECTRICAL CENTER (RIGHT FRONT WHEELHOUSE) AIR FUSE
I/P COMPART- MENT LAMP
I/P FUSE BLOCK (LEFT SIDE OF I/P)
I/P PANEL LAMP DIMMER ON
ILLUM ENTRY
INSIDE REAR VIEW MIRROR
INSTRUMENT CLUSTER SYSTEM ("GATE AJAR" INDICATOR)
INSTRUMENT CLUSTER SYSTEM (SEO ONLY) ("DOOR OPEN" INDICATOR)
JAMB SW
LEFT FRONT DOOR JAMB SWITCH
LEFT FRONT SIDE DOOR COURTESY LAMP
LEFT I/P COURTESY LAMP
LEFT REAR COMPART- MENT COURTESY LAMP (WAGON)
LEFT ROOF RAIL COURTESY AND READING LAMP
LEFT SUN- SHADE ILLUM- INATED MIRROR
NCA WIRE
ORG/ WIRE
PPL
REAR COMPARTMENT COURTESY LAMP
RIGHT FRONT DOOR JAMB SWITCH LEFT REAR DOOR JAMB SWITCH
RIGHT FRONT SIDE DOOR COURTESY LAMP
RIGHT I/P COURTESY LAMP
RIGHT REAR COMPART- MENT COURTESY LAMP (WAGON)
RIGHT REAR DOOR JAMB SWITCH
RIGHT ROOF RAIL COURTESY AND READING LAMP
RIGHT SUN- SHADE ILLUM- INATED MIRROR
SEATBELT/ IGNITION KEY/ LAMPS/ TURN SIGNAL ALARM
SEDAN
SEO
SEO ONLY
TAN WIRE
TRK LPS FUSE 27
UNDERHOOD LAMP
WAGON
WARNING SYSTEM
WHT WIRE
Go to component -> Courtesy lamps circuit -> I/P COMPART- MENT LAMP
