Chevrolet Impala VII (1994-1996) ignition key alarm switch Wiring diagram
This page shows the only wiring diagram for the component.ignition key alarm switch, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition key alarm switch (1 of 1)
1995 VFTC
AUTO HEADLAMP CONTROL MODULE (RIGHT KICK PANEL)
BLK WIRE
BLK/WHT WIRE
BLT SW
CHEVY BUICK
CHI BODY FUSE #13
CLUS CHI FUSE #33
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
DR SW PNK IGN WIRE
FASTEN BELTS INDICATOR
FUSE BLOCK- I/P
GRY WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN, BULB TEST OR START
IGN KEY
IGNITION KEY ALARM SWITCH
ILL ENT
IND CTRL
INSTRUMENT CLUSTER
LEFT FRONT DOOR JAMB SWITCH
LPS ON SIG
LT GRN WIRE
NCA WIRE
NON-SEO ONLY
ORG/ WIRE
PANEL LAMPS DIMMING MODULE
PNK WIRE
POWERTRAIN CONTROL MODULE
PPL
REMOTE KEYLESS ENTRY SYSTEM
RIGHT FRONT DOOR JAMB SWITCH LEFT REAR DOOR JAMB SWITCH
RIGHT REAR DOOR JAMB SWITCH
SAFETY BELT SWITCH
SUPPLEMENTAL RESTRAINT SYSTEM
T/SIG FUSE 12
TAN WIRE
TURN SIGNAL FLASHER (IN CONVENIENCE CENTER)
TURN/ HAZARD SWITCH
VEH SPD PPL TRN SIG ON
W/O TWILIGHT SENTINEL
W/TWILIGHT SENTINEL
WARNING ALARM (IN CONVENIENCE CENTER,
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> IGNITION KEY ALARM SWITCH
