Chevrolet Impala VII (1994-1996) hi mist lo off pulse pulse wiring diagram
This page shows the only wiring diagram for the component.hi mist lo off pulse pulse, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
hi mist lo off pulse pulse wiring diagram (1 of 1)
1995 VFTC
BLK WIRE
DK BLU WIRE
DK GRN WIRE
GRY WIRE
HI MIST
HI MIST LO OFF PULSE PULSE
HOT IN ACCY OR RUN
I/P FUSE BLOCK
LO HI END OF SWEEP INPUT CB
MECHANICAL ARM
MIST
NCA WIRE
OFF
OFF LO PULSE
OFF PULSE
PARK RELAY
PNK WIRE
PPL
RED WIRE
SOLID STATE TIMER RELAY
WASHER SWITCH
WINDSHIELD WASHER PUMP (ON WASHER FLUID RESERVOIR)
WINDSHIELD WIPER MOTOR
WIPER FUSE #10
WIPER/ WASHER SWITCH WIPER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> HI MIST LO OFF PULSE PULSE
