Chevrolet Impala VII (1994-1996) ground left front wheel sensor input left front wheel sensor grd Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 GROUND BATTERY BATTERY IGNITION 18 19 REAR WHEEL SENSOR INPUT REAR WHEEL SENSOR GRD 1995 VFTC ABS IND. ANTI-LOCK INDICATOR CONTROL BLK WIRE BLK/WHT WIRE BRAKE APPLIED SIGNAL SERIAL DATA LINE BRAKE PRESSURE MODULATOR VALVE (BPM) BRN WIRE CHEVROLET BUICK CONTROL SIGNALS DATA LINK CONN (DLC) (ATTACHED TO I/P CARRIER, RIGHT OF STEERING COLUMN) DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) ( LEFT FRONT OF ENG COMPT) FUSE BLOCK FUSE LINK B GROUND LEFT FRONT WHEEL SENSOR INPUT LEFT FRONT WHEEL SENSOR GRD HOT AT ALL TIMES HOT IN HOT IN RUN, BULB TEST OR START I/P INDIC FUSE INSTRUMENT CLUSTER LEFT FRONT WHEEL SPEED SENSOR LT BLU WIRE NCA WIRE ORG/ WIRE OUT PCM/IGN FUSE 5 PNK WIRE PUMP MOTOR PUMP MOTOR POWER OUTPUT REAR AXLE SPEED SENSOR RED WIRE RIGHT FRONT WHEEL SENSOR INPUT RIGHT FRONT WHEEL SENSOR GRD RIGHT FRONT WHEEL SPEED SENSOR RUN WIRE SOLENOID VALVES STOP LAMP SWITCH (ATTACHED TO BRAKE PEDAL BRACKET) STOP/HZD FUSE TAN WIRE UNDERHOOD ELECTRICAL CENTER VALVE POWER OUTPUT WHT WIRE YEL WIRE
