Chevrolet Impala VII (1994-1996) endgate upper latch switch Wiring diagram
This page shows the only wiring diagram for the component.endgate upper latch switch, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram endgate upper latch switch (1 of 1)
1995 VFTC
ACCESSORY SWITCH PANEL (LEFT I/P)
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER
DK BLU WIRE
ENDGATE LOCK SENSE SWITCH (CLOSED IN UNLOCK)
ENDGATE UPPER LATCH SWITCH
ENDGATE WINDOW RELEASE ACTUATOR
ENDGATE WINDOW RELEASE RELAY
ENDGATE WINDOW RELEASE SWITCH
HOT AT ALL TIMES
I/P FUSE BLOCK
ORG/ WIRE
ORG/BLK WIRE
PARK/ NEUTRAL POSITION SWITCH (ON STEERING COLUMN)
RR REL FUSE 29
UNLOCK
Go to component -> Rear glass release circuit, without keyless entry -> ENDGATE UPPER LATCH SWITCH
