Chevrolet Impala VII (1994-1996) change oil ind. ctrl mil ind. ctrl oil lvl input Wiring diagram

4 5 6 7 PNK WIRE AUX. DISPLAY GND AUX. DISPLAY PWR VIDEO IN #2 AUXILIARY GND SENSOR GND PAN/TILT GND BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE CHANGE OIL IND. CTRL MIL IND. CTRL OIL LVL INPUT CKT GDN CKT PWR DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE DOME COURTESY LAMP RELAY (CONVENIENCE CENTER, LEFT OF STEERING COLUMN) DOOR OPEN INPUT CENTER, LEFT OF STEERING COLUMN) E/M ENDGATE LOWER LOCK AJAR SWITCH (RIGHT SIDE OF TAILGATE) ENGINE OIL LEVEL SWITCH (OPEN WITH LOW OIL LEVEL) (LEFT SIDE OF ENGINE OIL PAN) GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES CTSY PWR LOCK FUSE 35 HOT IN ACCY OR RUN HUD ACSRY FUSE 7 HUD BATT FUSE 45 HUD PROJECTOR (SEO ONLY) I/P FUSE BLOCK ILLUM INSTRUMENT CLUSTER ENGLISH/ METRIC SWITCH LAMP GND LAMP PWR LEFT FRONT DOOR JAMB SWITCH LOW OIL LVL CTRL LT BLU WIRE LT GRN WIRE NCA WIRE NIGHT VISION CONTROL UNIT (CUSTOMER INSTALL) NIGHT VISION ROOF UNIT (EXTERIOR OF ROOF) NV BATT FUSE 26 ORG/ WIRE PAN/TILT GND PWR ON (DISCRETE) SERIAL COMMAND (-) SERIAL COMMAND (+) PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (IN ENG COMPT, UNDER AIR CLEANER) PPL RIGHT FRONT DOOR JAMB SWITCH LEFT REAR DOOR JAMB SWITCH RIGHT REAR DOOR JAMB SWITCH SEO TRIP RESET VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION, NEAR PROP SHAFT) VIDEO COAXIAL CABLE VSS INPUT VEHICLE SPEED OUTPUT 4000 P/M WARNING ALARM (CONVENIENCE RELAY CTRL WHT WIRE YEL WIRE YEL/BLK WIRE
