Chevrolet Impala VII (1994-1996) antenna input wiring diagram
This page shows the only wiring diagram for the component.antenna input, which is found in the car Chevrolet Impala VII (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
antenna input wiring diagram (1 of 1)
ANTENNA
ANTENNA INPUT
BATTERY POWER
BLK/WHT WIRE
BRN WIRE
COAXIAL CABLE
DIM SIGNAL
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY OR RUN
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
IGNITION POWER
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LT BLU WIRE
LT FRT SPKR
LT GRN WIRE
LT REAR SPKR
ON OUTPUT
ORG/ WIRE
PANEL LIGHT
POWER ANTENNA SYSTEM
RADIO
RADIO FUSE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RT FRT SPKR
RT REAR SPKR
SPEED COMPENSATED VOLUME
TAN WIRE
YEL WIRE
Go to component -> Radio circuits -> ANTENNA INPUT
