Car Wiring Diagrams for Heated steering wheel circuit for Chevrolet Impala IX (2006-2016)

BLK WIRE BLK/ VIO WIRE BLK/ WHT WIRE BLK/YEL WIRE BODY BRN WIRE FUSE GRY BRN/ WIRE GRY WIRE HEATED STEERING WHEEL HEATED STEERING WHEEL IND HEATED STEERING WHEEL SWITCH HOT W/ IGNITION MAIN RELAY ENERGIZED IGN LEFT STEERING WHEEL CONTROL SWITCH LOGIC LT BLU WIRE ORG/ WIRE PNK WIRE RED WIRE RIGHT STEERING WHEEL CONTROL SWITCH STEERING COLUMN FUSE HOLDER STEERING WHEEL AIR BAG COIL STEERING WHEEL HEATING CONTROL MODULE SW SIG LED CNTRL PNK WIRE UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) VIO/ BLK WIRE VOLT REF HI CNTRL WHT WIRE
