Chevrolet Impala IX (2006-2016) windshield washer Wiring diagram
This page shows the only wiring diagram for the component.windshield washer, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield washer (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRN/GRY WIRE
BRN/LT GRN WIRE
COMPUTER DATA LINES SYSTEM
DELAY SWITCH
DK BLU WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
ENGINE COMPT)
FRT WPR FUSE
FUSE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INT LOW OFF HIGH MIST WIPER SWITCH
INT OFF LOW MIST HIGH
LOW IND CTRL
LOW SPEED GMLAN SER DATA
LT GRN WIRE
MTR RELAY SPLY VOLT WIPER RLY CTRL
PUMP RELAY
SERIAL DATA
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF
VIO WIRE
WASHER FRT
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/VIO WIRE
WINDSHIELD WASHER
WINDSHIELD WASHER FLUID LEVEL SWITCH (IN WASHER FLUID CONTAINER)
WINDSHIELD WASHER PUMP (IN WASHER FLUID CONTAINER)
WINDSHIELD WASHER RLY CTRL
WINDSHIELD WASHER SW SIG
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER MOTOR PARK SW SIG
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED CONTROL RELAY
WINDSHIELD WIPER SW HIGH SIG
WINDSHIELD WIPER SW LOW REF
WINDSHIELD WIPER SW LOW SIG
WINDSHIELD WIPER/WASHER SWITCH
WIPER SW HI SIG
YEL/BRN WIRE
YEL/DK BLU WIRE
Go to component: -> Wiper/washer circuit -> WINDSHIELD WASHER
