Chevrolet Impala IX (2006-2016) windshield defrost windshield ind defrost switch Wiring diagram
This page shows the only wiring diagram for the component.windshield defrost windshield ind defrost switch, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield defrost windshield ind defrost switch (1 of 1)
A/C IND
A/C LOW REF
A/C PRESS SENS SIG
A/C SWITCH
AUTO IND
AUTO SWITCH
B+ BUS 9 SERIAL DATA GND
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLOWER TEMPERATURE SWITCH IND
BRN/RED WIRE
BRN/YEL WIRE
CMPRSR CLUTCH RLY CTRL
COMPUTER DATA LINES SYSTEM
COOLING FAN RELAY CTRL
DEFROST, LOWER AIR OUTLET IND
DEFROST, LOWER AIR OUTLET SWITCH
DK BLU WIRE
DK BLU/GRY WIRE
GMLAN SERIAL DATA
GRY WIRE
HI SPD
HVAC CONTROLS
IND LOWER AIR OUTLET SWITCH
LEFT COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
LO SPD
LOGIC
LOWER AIR OUTLET
LT GRN WIRE
LT GRN/VIO WIRE
LT GRN/YEL WIRE
MAIN RLY FUSE SPLY
RECIRCULATION IND
RECIRCULATION SWITCH
RED/DK BLU WIRE
SENS LO REF
SENS SIG ENG COOLANT TEMP
SIG GND
TEMPERATURE CONTROL SWITCH
TEMPERATURE SWITCH
UPPER AIR OUTLET IND
UPPER AIR OUTLET SWITCH
UPPER, LOWER AIR OUTLET IND
UPPER, LOWER AIR OUTLET SWITCH
VIO/DK BLU WIRE
WHT WIRE
WHT/GRY WIRE
WINDSHIELD DEFROST WINDSHIELD IND DEFROST SWITCH
Go to component: -> Manual a/c circuit (4 of 4) -> WINDSHIELD DEFROST WINDSHIELD IND DEFROST SWITCH
