Chevrolet Impala IX (2006-2016) underhood fuse block (right side wiring diagram
This page shows the only wiring diagram for the component.underhood fuse block (right side, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
underhood fuse block (right side wiring diagram (1 of 1)
2.4L
BATT POSI VOLT
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COOL FAN HI FUSE
COOL FAN LO FUSE
COOL TEMP SENS LO
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN SPEED CONTROL RELAY
DK BLU WIRE
ECM BATT FUSE
ENG COOLANT TEMP SENS SIG
ENGINE CONTROL MODULE (INSIDE AIR CLEANER ASSEMBLY)
ENGINE CONTROLS IGNITION RELAY
ENGINE COOLANT TEMPERATURE GAUGE
EXCEPT 2.4L
FAN RLY A FUSE
GRN/VIO WIRE
GRY WIRE
GRY/VIO WIRE
HI SPD COOLING FAN RLY CTRL HI SPD GMLAN SERIAL DATA (-) 1
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY FUSE BLOCK FUSE
INSTRUMENT CLUSTER
LEFT COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
LO SPD COOLING FAN RLY CTRL
LOGIC MOST SERIAL DATA (+)
LT GRN/VIO WIRE
MOST SERIAL DATA (+)
OF ENGINE COMPT)
RED WIRE
RED/BRN WIRE
RED/WHT WIRE
RIGHT COOLING FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
UNDERHOOD FUSE BLOCK (RIGHT SIDE
WHT WIRE
WHT/DK BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> UNDERHOOD FUSE BLOCK (RIGHT SIDE
