Chevrolet Impala IX (2006-2016) transmission park/ neutral signal 1 Wiring diagrams

This page contains all the electrical diagrams for the component. transmission park/ neutral signal 1, in which he is found in the car Chevrolet Impala IX (2006-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram transmission park/ neutral signal 1 (1 of 3)

Wiring diagram transmission park/ neutral signal 1 for Chevrolet Impala IX (2006-2016)

Get access

AUTOMATIC TRANSMISSION ASSEMBLY BATTERY BATTERY FUSE BLOCK BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE ECM IGN FUSE ENGINE CONTROL MODULE (INSIDE AIR CLEANER ASSEMBLY) FUSE 5 FUSE 6 GMLAN SERIAL DATA - 1 GROUND DISTRIBUTION SYSTEM HIGH SPEED GMLAN SERIAL DATA (-) (1) HOT W/ IGNITION MAIN RELAY ENERGIZED IGN KEY SIG IGN MODE SW IGN VOLT IGNITION MODE SWITCH (W/ KEYLESS SWITCH) IGNITION SWITCH (W/O KEYLESS SWITCH) OFF RED WIRE RUN WIRE RUN/CRANK IGN 1 VOLT STARTER ENABLE RELAY CTRL STARTER FUSE STARTER MOTOR STARTER RELAY TRANSMISSION CONTROL MODULE TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION PARK/ NEUTRAL SIGNAL 1 UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) VIO/GRY WIRE VIO/LT GRN WIRE WHT WIRE WHT/GRY WIRE YEL WIRE

Go to component: -> 2.4l vin r, starting circuit -> TRANSMISSION PARK/ NEUTRAL SIGNAL 1

Wiring diagram transmission park/ neutral signal 1 (2 of 3)

Wiring diagram transmission park/ neutral signal 1 for Chevrolet Impala IX (2006-2016)

Get access

2.5L 2.5L 3.6L 3.6L 2.5L AUTOMATIC TRANSMISSION ASSEMBLY BATTERY BATTERY FUSE BLOCK BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN WIRE CHARGING CIRCUIT COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE ECM IGN FUSE ENGINE CONTROL MODULE (INSIDE AIR CLEANER ASSEMBLY) FUSE 5 FUSE 6 GMLAN SERIAL DATA - 1 GROUND DISTRIBUTION SYSTEM HIGH SPEED GMLAN SERIAL DATA (-) (1) HOT W/ IGNITION MAIN RELAY ENERGIZED IGN KEY SIG IGN MODE SW IGN VOLT IGNITION MODE SWITCH (W/ KEYLESS SWITCH) IGNITION SWITCH (W/O KEYLESS SWITCH) OFF RED WIRE RUN WIRE RUN/CRANK IGN 1 VOLT STARTER ENABLE RELAY CTRL STARTER FUSE STARTER MOTOR STARTER RELAY TRANSMISSION CONTROL MODULE TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION PARK/ NEUTRAL SIGNAL 1 UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) VIO/LT GRN WIRE WHT WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE

Go to component: -> 2.5l vin l, starting circuit -> TRANSMISSION PARK/ NEUTRAL SIGNAL 1

Wiring diagram transmission park/ neutral signal 1 (3 of 3)

Wiring diagram transmission park/ neutral signal 1 for Chevrolet Impala IX (2006-2016)

Get access

2.5L 2.5L 3.6L 3.6L 2.5L AUTOMATIC TRANSMISSION ASSEMBLY BATTERY BATTERY FUSE BLOCK BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN WIRE CHARGING CIRCUIT COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE ECM IGN FUSE ENGINE CONTROL MODULE (INSIDE AIR CLEANER ASSEMBLY) FUSE 5 FUSE 6 GMLAN SERIAL DATA - 1 GROUND DISTRIBUTION SYSTEM HIGH SPEED GMLAN SERIAL DATA (-) (1) HOT W/ IGNITION MAIN RELAY ENERGIZED IGN KEY SIG IGN MODE SW IGN VOLT IGNITION MODE SWITCH (W/ KEYLESS SWITCH) IGNITION SWITCH (W/O KEYLESS SWITCH) OFF RED WIRE RUN WIRE RUN/CRANK IGN 1 VOLT STARTER ENABLE RELAY CTRL STARTER FUSE STARTER MOTOR STARTER RELAY TRANSMISSION CONTROL MODULE TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION PARK/ NEUTRAL SIGNAL 1 UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) VIO/LT GRN WIRE WHT WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE

Go to component: -> 3.6l vin 3, starting circuit -> TRANSMISSION PARK/ NEUTRAL SIGNAL 1
