Chevrolet Impala IX (2006-2016) starter/generator control module hybrid/ev battery pack Wiring diagram
This page shows the only wiring diagram for the component.starter/generator control module hybrid/ev battery pack, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram starter/generator control module hybrid/ev battery pack (1 of 1)
2.4L, 2.5L CONTROL SOLENOID VALVE ASSEMBLY
3.6L
5 6 ACC VOLT RUN/CRANK
ACC LED LED SIG
ACC VOLT
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/GRY WIRE
BODY CONTROL MODULE
BPIM BATT FUSE
BRN WIRE
CANN VENT FUSE
COOL
COOLING FAN HIGH SPEED RELAY
DK BLU WIRE
DK BLU/BLK WIRE
EVAPORATIVE EMISSION VENT SOLENOID VALVE
EXCEPT HYBRID
EXCEPT HYBRID HYBRID
FROM HEADLAMP HIGH BEAM RELAY (DIAGRAM 5 OF 6)
FROM INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 2 OF 6)
FUSE
HYBRID EXCEPT HYBRID
IGN
IGN 1 VOLT
IGNITION MODE SWITCH (W/ KEYLESS ENGINE START SWITCH)
IGNITION SWITCH (W/O KEYLESS ENGINE
KEY-IN IGNITION SWITCH
KEYLESS ENTRY CONTROL MODULE
LED SIG 22 15
LOW REF
LT GRN/BLK WIRE
LT GRN/VIO WIRE
MODE CTRL
MODE VOLT
OFF
PPL
RED/BRN WIRE
RED/GRN WIRE
RED/LT GRN WIRE
RED/WHT WIRE
RUN WIRE
RUN/CRANK IGN 1 VOLT
RUN/CRANK RLY COIL CTRL
STARTER/GENERATOR CONTROL MODULE
STARTER/GENERATOR CONTROL MODULE HYBRID/EV BATTERY PACK
SWITCH
TCM BATT FUSE
TO UNDERHOOD FUSE BLOCK (DIAGRAM 2 OF 6)
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT)
VIO/BLK WIRE
VIO/YEL WIRE
W/ KEYLESS ENGINE START SWITCH
W/O KEYLESS ENGINE START SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> STARTER/GENERATOR CONTROL MODULE HYBRID/EV BATTERY PACK
