Chevrolet Impala IX (2006-2016) serial data ign wiring diagram

1 3 5 BATT POSITIVE VOLT BATT POSITIVE VOLT RF TURN SIG LAMP 13 12 LF TRL TURN SIG LP RT TRL TURN SIG LP 14 15 13 10 LOW REF 5 VOLT REF STOP LAMP SW SIG SERIAL DATA 19 16 15 HAZARD SW SIG RIGHT TURN SW SIG LEFT TURN SW SIG BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU/WHT WIRE DK GRN WIRE DK GRN/BLK WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY GRY WIRE HAZARD HEAD HEADLAMP SWITCH HOT AT ALL TIMES IGN INSTRUMENT PANEL CLUSTER (IPC) LAMP LEFT LEFT EMERGENCY VEHICLE REAR WINDOW PANEL LAMP (IF EQUIPPED) LEFT FRONT LEFT PARK/ TURN SIGNAL LEFT SPOT LAMP LEFT TURN INDICATOR LOGIC LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT PARK FUSE LT SPOT FUSE LT T/SIG FUSE MARKER LAMP NCA WIRE ORG/ WIRE PARK AUTO OFF PARK LAMP SW SIG PARK LP PCB RELAY POLICE PPL RED WIRE RED/WHT WIRE RIGHT RIGHT FRONT MARKER LAMP RIGHT PARK/ RIGHT SPOT LAMP RIGHT TURN INDICATOR RT PARK FUSE RT SPOT FUSE RT T/SIG FUSE SERIAL DATA SERIAL DATA IGN TAN WIRE TURN SIGNAL LAMP TURN SIGNAL/ MULTI-FUNCTION SWITCH WHT WIRE YEL WIRE
