Chevrolet Impala IX (2006-2016) right temperature control blower switch switch Wiring diagram

"A" PILLAR) A/C CLUTCH FUSE A/C COMPRESSOR CLUTCH RELAY A/C IND A/C SWITCH AUTO IND AUTO SWITCH B+ BUS 9 SER DATA GND BLK WIRE BLK/BRN WIRE BRN/LT GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOL FAN HI FUSE COOL FAN LO FUSE COOLING FAN HIGH SPEED RELAY COOLING FAN LOW SPEED RELAY COOLING FAN SPEED CONTROL RELAY DEFROST, DEFROST, LOWER AIR OUTLET IND LOWER AIR OUTLET SWITCH DRIVER INFORMATION CENTER DISPLAY ENGINE CONTROLS IGNITION RELAY ENGINE COOLANT TEMPERATURE GAUGE EXCEPT 2.4L 2.4L FAN RLY A FUSE GMLAN GRN/VIO WIRE GRY WIRE HOT AT ALL TIMES HVAC CONTROLS INSTRUMENT CLUSTER LEFT TEMPERATURE CONTROL SWITCH LOGIC LOW SPEED LOWER AIR OUTLET IND LOWER AIR OUTLET SWITCH LT GRN WIRE LT GRN/VIO WIRE LT GRN/YEL WIRE RECIRCULATION IND RECIRCULATION SWITCH RED WIRE RED/DK BLU WIRE RED/WHT WIRE RIGHT TEMPERATURE CONTROL BLOWER SWITCH SWITCH SERIAL DATA SYNC IND SYNC SWITCH UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT) UPPER AIR OUTLET IND UPPER AIR OUTLET SWITCH UPPER, LOWER AIR OUTLET IND UPPER, LOWER AIR WINDSHIELD OUTLET DEFROST SWITCH IND WHT WIRE WHT/DK BLU WIRE WHT/GRY WIRE WINDSHIELD DEFROST SWITCH YEL WIRE
