Chevrolet Impala IX (2006-2016) right sunshade mirror lamp Wiring diagrams
This page contains all the electrical diagrams for the component. right sunshade mirror lamp, in which he is found in the car Chevrolet Impala IX (2006-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right sunshade mirror lamp (1 of 2)
BATT POS VOLT
BCM 2 FUSE
BCM 5 FUSE
BCM 7 FUSE
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
CENTER CONSOLE COMPARTMENT LAMP
CM FORWARD OF BREAKOUT
COMPUTER DATA LINES SYSTEM
COURTESY LAMP
DK BLU WIRE
DOME LAMP SWITCH
DRIVER INFORMATION CENTER DISPLAY
GMLAN SERIAL DATA
GRY WIRE
GRY/LT GRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INADVERTENT PWR CTRL
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION CIRCUIT
INSTRUMENT PANEL COMPARTMENT LAMP
INSTRUMENT PANEL COMPARTMENT LAMP SWITCH
INSTRUMENT PANEL FUSE BLOCK (RIGHT
INTR LP CTRL
INTR LP DEFEAT SW SIG COURTESY LP SW SIG
KICK PANEL)
LED AMBIENT LIGHTING CTRL 1
LEFT FRONT DOME/ READING LAMPS
LEFT SUNSHADE
LEFT SUNSHADE MIRROR LAMP
LIFT GATE AJAR SW SIG
LOGIC
LT GRN WIRE
LT GRN/GRY WIRE
NCA WIRE
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH
REAR DOME READING LAMPS
RED WIRE
RED/BRN WIRE
RED/LT GRN WIRE
RIGHT FRONT DOME/ READING LAMPS
RIGHT INSTRUMENT PANEL
RIGHT SUNSHADE
RIGHT SUNSHADE MIRROR LAMP
TRUNK LP CTRL
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> RIGHT SUNSHADE MIRROR LAMP
Wiring diagram right sunshade mirror lamp (2 of 2)
BLK WIRE
CENTER CONSOLE FLOOD LAMP
CENTER HIGH MOUNTED STOP LAMP
CHASSIS CONTROL MODULE
COMPASS MODULE
LAMP
LEFT BACKUP LAMP
LEFT FRONT DOME/READING LAMPS
LEFT LEFT REAR TAIL/STOP SIDE AND TURN MARKER SIGNAL LAMP LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR SEAT SIDE AIR BAG
LEFT SIDE OBJECT SENSOR MODULE
LEFT SUNSHADE MIRROR LAMP
LEFT TAIL LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAIL/STOP AND TURN
LOGIC
PARKING BRAKE CONTROL MODULE
PASSENGER DOME AIR BAG LAMP DISABLE SWITCH INDICATOR
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH
REAR DOME/READING LAMPS
RIGHT BACKUP LAMP
RIGHT FRONT DOME/READING LAMPS
RIGHT LICENSE PLATE LAMP
RIGHT RIGHT REAR SIDE MARKER TAIL LAMP ASSEMBLY
RIGHT SIDE OBJECT SENSOR MODULE
RIGHT SUNSHADE MIRROR LAMP
RIGHT TAIL LAMP
SIGNAL LAMP
SUNROOF SWITCH (W/ ELECTRIC SLIDING GLASS SUNROOF)
TELEMATICS BUTTON ASSEMBLY
W/ ONSTAR
W/ SIDE OBSTACLE DETECTION, REAR CROSS TRAFFIC ALERT
W/O ONSTAR
YEL WIRE
Go to component -> Ground distribution circuit (7 of 7) -> RIGHT SUNSHADE MIRROR LAMP
