Chevrolet Impala IX (2006-2016) park/ neutral sig 1 Wiring diagrams

This page contains all the electrical diagrams for the component. park/ neutral sig 1, in which he is found in the car Chevrolet Impala IX (2006-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram park/ neutral sig 1 (1 of 3)

Wiring diagram park/ neutral sig 1 for Chevrolet Impala IX (2006-2016)

Get access

ASSEMBLY AUTOMATIC TRANSMISSION BLK WIRE BLU WIRE BUS 2 NETWORK COIL CTRL COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DRIVER INFORMATION CENTER DISPLAY ENGINE CONTROL MODULE (INSIDE AIR CLEANER ASSEMBLY) FROM CONTROL SOLENOID VALVE ASSEMBLY (DIAGRAM 1 OF 2) GMLAN SER DATA GRN WIRE GRY WIRE GRY/VIO WIRE INSTRUMENT CLUSTER ISS HIGH SIGNAL ISS LOW SIGNAL LO SPD LOGIC LOW REF LT GRN WIRE LT GRN/DK BLU WIRE OSS HIGH SIGNAL OSS LOW SIGNAL P/N PARK/ NEUTRAL SIG 1 POWER DISTRIBUTION SYSTEM RAP RLY RED WIRE SENSOR SER DATA (-) 1 HI SPD GMLAN TRANSMISSION CONTROL MODULE TRANSMISSION FLUID PRESSURE SWITCH TRANSMISSION INPUT SHAFT SPEED TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION OUTPUT SHAFT SPEED TRANSMISSION RANGE SWITCH SIG A TRANSMISSION RANGE SWITCH SIG B TRANSMISSION RANGE SWITCH SIG C TRANSMISSION RANGE SWITCH SIG P TRANSMISSION SHIFT LEVER POSITION INDICATOR WHT WIRE WHT/GRY WIRE YEL WIRE

Go to component: -> 2.4l vin r, transmission circuit (2 of 2) -> PARK/ NEUTRAL SIG 1

Wiring diagram park/ neutral sig 1 (2 of 3)

Wiring diagram park/ neutral sig 1 for Chevrolet Impala IX (2006-2016)

Get access

ASSEMBLY AUTOMATIC TRANSMISSION BLK WIRE BLU WIRE BUS 2 NETWORK COIL CTRL COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DRIVER INFORMATION CENTER DISPLAY ENGINE CONTROL MODULE (INSIDE AIR CLEANER ASSEMBLY) FROM CONTROL SOLENOID VALVE ASSEMBLY (DIAGRAM 1 OF 2) GMLAN SER DATA GRN WIRE GRY WIRE GRY/VIO WIRE INSTRUMENT CLUSTER ISS HIGH SIGNAL ISS LOW SIGNAL LO SPD LOGIC LOW REF LT GRN WIRE LT GRN/DK BLU WIRE OSS HIGH SIGNAL OSS LOW SIGNAL P/N PARK/ NEUTRAL SIG 1 POWER DISTRIBUTION SYSTEM RAP RLY RED WIRE SENSOR SER DATA (-) 1 HI SPD GMLAN TRANSMISSION CONTROL MODULE TRANSMISSION FLUID PRESSURE SWITCH TRANSMISSION INPUT SHAFT SPEED TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION OUTPUT SHAFT SPEED TRANSMISSION RANGE SWITCH SIG A TRANSMISSION RANGE SWITCH SIG B TRANSMISSION RANGE SWITCH SIG C TRANSMISSION RANGE SWITCH SIG P TRANSMISSION SHIFT LEVER POSITION INDICATOR WHT WIRE WHT/GRY WIRE YEL WIRE

Go to component: -> 2.5l vin l, transmission circuit (2 of 2) -> PARK/ NEUTRAL SIG 1

Wiring diagram park/ neutral sig 1 (3 of 3)

Wiring diagram park/ neutral sig 1 for Chevrolet Impala IX (2006-2016)

Get access

ASSEMBLY AUTOMATIC TRANSMISSION BLK WIRE BUS 2 NETWORK COIL CTRL COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DRIVER INFORMATION CENTER DISPLAY ENGINE CONTROL MODULE (INSIDE AIR CLEANER ASSEMBLY) GMLAN SER DATA GRN WIRE GRY WIRE GRY/VIO WIRE INSTRUMENT CLUSTER ISS HIGH SIGNAL ISS LOW SIGNAL LO SPD LOGIC LOW REF LT GRN WIRE LT GRN/DK BLU WIRE OSS HIGH SIGNAL OSS LOW SIGNAL P/N PARK/ NEUTRAL SIG 1 RAP RLY RED WIRE SENSOR SER DATA (-) 1 HI SPD GMLAN TRANSMISSION CONTROL MODULE TRANSMISSION FLUID PRESSURE SWITCH TRANSMISSION INPUT SHAFT SPEED TRANSMISSION INTERNAL MODE SWITCH TRANSMISSION OUTPUT SHAFT SPEED TRANSMISSION RANGE SWITCH SIG A TRANSMISSION RANGE SWITCH SIG B TRANSMISSION RANGE SWITCH SIG C TRANSMISSION RANGE SWITCH SIG P TRANSMISSION SHIFT LEVER POSITION INDICATOR WHT WIRE WHT/GRY WIRE YEL WIRE

Go to component: -> 3.6l vin 3, transmission circuit (2 of 2) -> PARK/ NEUTRAL SIG 1
