Chevrolet Impala IX (2006-2016) mal- function lamp ind Wiring diagram

A/C COMPRESSOR CLUTCH RELAY ACTIVE GRILLE AIR SHUTTER ACTUATOR (FRONT CENTER OF OF GRILLE OPENING) BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/LT GRN WIRE BLK/YEL WIRE BLU/BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CCM FUSE CHASSIS CONTROL MODULE (RIGHT REAR LUGGAGE COMPT) COMMUNICATION ENABLE COMPUTER DATA LINES SYSTEM COOLING FAN HIGH SPEED RELAY DK BLU WIRE DK BLU/BRN WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ECM CANN BATT VENT FUSE FUSE ECM IGN FUSE FLP SENS FPP RLY CTRL FROM ENGINE CONTROL IGNITION RELAY (DIAGRAM 4 OF 5) FUEL PRESSURE SENSOR (RIGHT SIDE OF FUEL TANK) GMLAN SERIAL DATA GROUND GRY WIRE GRY/BLK WIRE GRY/DK BLU WIRE HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED IGN IGN 1 VOLT IND CTRL INSTRUMENT CLUSTER LOGIC LOGIC LOW REF LT GRN WIRE LT GRN/DK BLU WIRE LT GRN/GRY WIRE MAL- FUNCTION LAMP IND OIL LEVEL IND POWER DISTRIBUTION SYSTEM PRESS SENS SIG RED WIRE RED/BRN WIRE RED/LT GRN WIRE RED/VIO WIRE RUN/CRANK SAIR PUMP FUSE SAIR SOL FUSE SECONDARY AIR INJECTION SECONDARY AIR INJECTION PUMP RELAY (CALIFORNIA) SERIAL DATA SHIELD EXTENSION SHUTTER VALVE SOL CTRL SOLENOID VALVE RELAY (CALIFORNIA) SPLY VOLT FUEL PUMP TCM/ AERO CCM FUSE IGN FUSE VIO/BLK WIRE VIO/DK BLU WIRE VIO/GRY WIRE VIO/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE YEL WIRE
