Chevrolet Impala IX (2006-2016) left high beam headlamp Wiring diagrams
This page contains all the electrical diagrams for the component. left high beam headlamp, in which he is found in the car Chevrolet Impala IX (2006-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left high beam headlamp wiring diagram (1 of 2)
AUDIO AMPLIFIER
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID
AUXILIARY FUSE BLOCK
BLK WIRE
BLOWER MOTOR CONTROL MODULE
DATA LINK CONNECTOR (DLC)
DIGITAL RADIO RECEIVER
DRIVER INFORMATION CENTER (DIC) SWITCH
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
EMERGENCY VEHICLE HEADLAMP FLASHER
ENHANCED AUDIO
FAN 2 RELAY
HORN ASSEMBLY
HORN SWITCH
HVAC CONTROL MODULE
I/P ACCESSORY POWER OUTLET 1
I/P ACCESSORY POWER OUTLET 2
IGNITION LOCK CYLINDER CONTROL ACTUATOR
INFLATABLE RESTRAINT I/P MODULE INDICATOR
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (UNDER STEERING WHEEL)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT HOOD FOG AJAR LAMP SWITCH
LEFT HIGH BEAM HEADLAMP
LEFT I/P COURTESY LAMP
LEFT LEFT FRONT LOW MARKER BEAM LAMP HEADLAMP
LEFT PARK/ TURN SIGNAL LAMP
LEFT STEERING WHEEL CONTROL SWITCH
NCA WIRE
POLICE
REAR DEFOG RELAY
RIGHT ENGINE COOLING FAN
RIGHT ENGINE COOLING FAN DIODE
RIGHT FRONT FOG LAMP
RIGHT FRONT MARKER LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT I/P COURTESY LAMP
RIGHT LOW BEAM HEADLAMP
RIGHT PARK/TURN SIGNAL LAMP
RIGHT STEERING WHEEL CONTROL SWITCH
SECONDARY AIR INJECTION (AIR) PUMP
SEO 1 SEO 2 RELAY RELAY
SPEAKER SYSTEM
STEERING WHEEL MODULE
W/ CRUISE CONTROL ACCESSORY STEERING WHEEL CONTROL
W/ DIGITAL AUDIO SYSTEM
W/ EMISSION SYSTEM
W/ FLOOR CONSOLE
W/ HEADLAMP FLASHER
W/ POLICE W/ REMOTE KEYLESS ENTRY IF EQUIPPED
W/O CRUISE CONTROL ACCESSORY STEERING WHEEL CONTROL
W/O FLOOR CONSOLE
W/O HEADLAMP FLASHER
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WASHER FLUID PUMP DIODE
WINDSHIELD WIPER MOTOR
WIPER PCB RELAY
Go to component -> Ground distribution circuit (3 of 3) -> LEFT HIGH BEAM HEADLAMP
left high beam headlamp wiring diagram (2 of 2)
10 21 GMLAN SER DATA FOG LMP SW SIG
12 17 11 HEADLAMP ON SW HEADLAMP OFF SW AMB LMP SENS SIG
23 16 11 DRL PCB RLY CTRL HI BEAM RLY CTRL FOG LMP RLY CTRL
AMBIENT LIGHT SENSOR (TOP CENTER OF DASH)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/BLK WIRE
DK GRN/WHT WIRE
DRL 1 FUSE
DRL RELAY
FOG LAMP SWITCH
FOG LAMPS FUSE
FOG LP RELAY
FTP
GRN WIRE
GRY WIRE
HEAD PARK AUTO
HEADLAMP SWITCH
HIGH BEAM RELAY
HIGH PPL
HOT AT ALL TIMES
IGN
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT FOG LAMP
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LOGIC
LOW BEAM RELAY
LOW BEAM RLY CTRL
LT GRN WIRE
LT GRN/BLK WIRE
LT LO BEAM FUSE DRL 2 FUSE
OFF
ORG/ WIRE
ORG/BLK WIRE
PARK BRAKE SW
PARK BRAKE SWITCH (PARK BRAKE ASSEMBLY)
PNK WIRE
PNK/WHT WIRE
PPL
PPL 18 25 DIMMER SW HI BM SIG FTP SW SIG
RIGHT FRONT FOG LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
RT HI BEAM FUSE LT HI BEAM FUSE
RT LO BEAM FUSE
SER DATA FOG LAMP IND IGN
SER DATA HIGH BEAM IND LO SPD GMLAN SER DATA
TAN WIRE
TAN/WHT WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, without police -> LEFT HIGH BEAM HEADLAMP
