Chevrolet Impala IX (2006-2016) key capture solenoid actuator Wiring diagram
This page shows the only wiring diagram for the component.key capture solenoid actuator, which is found in the car Chevrolet Impala IX (2006-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key capture solenoid actuator (1 of 1)
24 25 1 SERIAL DATA (-) SERIAL DATA (+) GND
2501 2500 1650 COMPUTER DATA LINES SYSTEM
5 VOLT REF
7493 7494 COMPUTER DATA LINES SYSTEM
ACCESSORY VOLTAGE
APPLY SENS SIG
BCM 6 FUSE
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY)
BRK POS SENS SIG
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/GRY WIRE
DK BLU/YEL WIRE
DLIS FUSE BLOCK FUSE (RIGHT KICK PANEL)
ENGINE CONTROL MODULE (ECM) (INSIDE AIR CLEANER ASSEMBLY) 16 17
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
IGNITION SWITCH (W/O KEYLESS ENGINE START SWITCH)
INSTRUMENT PANEL
KEY CAPTURE SOLENOID ACTUATOR
KEY-IN SWITCH
LOW REF
OFF
OFF/RUN/CRANK VOLTAGE
PARK POSITION SWITCH
RED/WHT WIRE
RUN WIRE
SERIAL DATA (-) SERIAL DATA (+)
SHIFT POS SIG
SUPPLY VOLTAGE
TRANSMISSION SHIFT LEVER
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT)
VIO/YEL WIRE
WHT WIRE
WHT/LT GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
Go to component: -> Ignition lock solenoid circuit -> KEY CAPTURE SOLENOID ACTUATOR
