Chevrolet Impala IX (2006-2016) ign 1 volt b+ pdl pos low ref Wiring diagram

2500 2501 COMPUTER DATA LINES SYSTEM 7493 7494 COMPUTER DATA LINES SYSTEM A/C SENS SIG ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) AIR CONDITIONING SYSTEM APP SENS SIG 1 APP SIG BLK/BRN WIRE BLK/DK BLU WIRE BLK/GRN WIRE BLK/LT GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRN WIRE BLU/VIO WIRE BLU/WHT WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CHECK ENG IND CTRL CMPSR CLTCH RLY CTRL COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM CRUISE CONTROL SYSTEM DK BLU WIRE DK BLU/BRN WIRE DK BLU/GRY WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE ENG RLY CTRL IGN 1 VOLT ENGINE CONTROL MODULE (INSIDE AIR CLEANER ASSEMBLY) EVAPORATIVE EMISSION CANISTER VENT SOLENOID (RIGHT OF FUEL TANK) FAN RLY CTRL FUEL LVL SEN SIG FUEL LVL SENS LO REF FUEL PRES SENS SIG FUEL PUMP RLY CTRL FUEL PUMP, LEVEL SENSOR ASSEMBLY (TOP OF FUEL TANK) GRN WIRE GRY WIRE HI SER DATA BUS (+) HI SER DATA BUS (-) IGN 1 VOLT B+ PDL POS LOW REF IGN STARTER RLY CTRL LOW REF LT GRN WIRE LT GRN/DK BLU WIRE LT GRN/GRY WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE PDL POS LOW REF RED/BRN WIRE RED/GRN WIRE RED/LT GRN WIRE SEC AIR INJ SOL SIG SOLENOID CTRL SOLENOID CTRL SOLENOID CTRL CRUISE/ETC/TCC BRAKE SIG STARTING/CHARGING SYSTEM VIO/DK BLU WIRE VIO/GRY WIRE VIO/LT GRN WIRE VIO/YEL WIRE WAKE-UP SER DATA WHT WIRE WHT/DK BLU WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE YEL/WHT WIRE
